Permanent Anti-Slip Road Marking Tapes
01
Permanent Anti-stain&anti-slip pavement marking tapes (Particles Surface)
Product Information
Brand: Color Road
Color: white, yellow, red, blue, black, green
Product Features
--Preformed reflective marking tape, which can be made into any specification according to customer requirements.
--The preformed material substrate is composed of polymer flexible polymer rubber, fillers, pigments, etc., and a layer of high wear-resistant environmental protection paint and anti-skid particles are planted on the surface. It has anti-fouling and anti-skid, strong wear resistance, good weather resistance, and durability. Long life, convenient and fast construction, and so on.
--Applicable to concrete, asphalt, cement, marble, and other road surfaces and walls of various materials. Widely used in railway stations, bus stations, shopping malls, hotels, hotels, hospitals, schools, playgrounds, factories, workshops, canteens, warehouses, etc.
--Can be made into various marking lines, arrows, words, patterns, colored sign markings on road surfaces, colored three-dimensional signs, and pipeline signs.
--Depending on the condition of the road surface, traffic flow, and installation, the service life can be at least 2 years.
Product size reference chart
| Product number | Standard Length（m) | Standard Width（cm) | Thickness（mm) | Weight（±10%） | Conventional packaging | Adhesive |
| L-40X | 40M | 5,10,15,20， within 100 customizable | 1.2MM | 2.2kg/sqm | 300*300*320MM | without adhesive backing |
| L-41X | 40M | 5,10,15,20， within 100 customizable | 1.4MM | 2.4kg/sqm | 300*300*320MM | with adhesive backing |
Technical Indicators
| Properties |
Typical data |
unit |
Test Methods |
|
|
________ |
________ |
|||
|
color |
white |
yellow |
________ |
________ |
|
thickness |
1.2 |
1.2 |
mm |
GB/T 7125 |
|
water resistance |
pass |
pass |
________ |
GB/ T24717 |
|
acid resistance |
pass |
pass |
________ |
GB/T 24717 |
|
Wear-resistant |
40 |
40 |
mg |
GB/T24717 |
|
minimum adhesion |
25 |
25 |
N/25mm |
GB/T24717 |
|
Anti-skid value |
>45；>55 |
>45；>55 |
BPN |
GB/T24717 |
Instructions
1. The pavement marking tape without adhesive backing is commonly used in special environments and special materials, using special glue, such as two-component AB glue, 502 glue, etc.
2. The products with adhesive backing can be divided into ground brush primer and ground primer without brush according to the usage:
Without brush primer on the ground: It can be directly applied to smooth and flat surfaces without applying primer when used indoors, on outer pavement, and various walls of place such as workshops, exhibition halls, squares, safety islands of toll stations, where few vehicles run over, it only needs rip off the isolated paper on the back of the product and sticks it directly to the joint surface. And its life can be 5 years to the longest.
Brush primer on the ground: It should be applied with primer on uneven surfaces or walls(e.g., Pattex Contact Adhesive, Maxbond UL 1603HFR-HS). The amount of primer required depends on the smoothness of the bonding surface, approximately 1 kilogram per 3 to 5 square meters. Please refer to the construction instructions when using the primer.
